OPTIdrill DH 34BV


Bench drills and upright drilling machines with infinitely variable mechanical gearbox

Convincing arguments: quality, efficiency and price
· Smooth running and powerful electrical motor
· Long, ergonomic aluminium die-cast spindle sleeve lever made of one piece with Softgrip handles (DH 24BV)
· Spindle sleeve lever made of steel (DH 28BV/ DH 34BV)
· Base plate usable as a working surface for extra high workpieces due to the pivoting the drilling table away
· Right-hand/left-hand rotation
· 2 speed stages
· Easy tool change due to integrated drill drift from OPTIdrill DH 34BV

Technical data and accessories




Αγορα Λεπτομερειες

OPTIdrill DH 28BV


Bench drills and upright drilling machines with infinitely variable mechanical gearbox

Convincing arguments: quality, efficiency and price
· Smooth running and powerful electrical motor
· Long, ergonomic aluminium die-cast spindle sleeve lever made of one piece with Softgrip handles (DH 24BV)
· Spindle sleeve lever made of steel (DH 28BV/ DH 34BV)
· Base plate usable as a working surface for extra high workpieces due to the pivoting the drilling table away
· Right-hand/left-hand rotation
· 2 speed stages
· V-belt cover with safety switch from OPTIdrill DH 28BV
· Easy tool change due to integrated drill drift

Technical data and accessories




Αγορα Λεπτομερειες

OPTIdrill Β 34H


Robust bench drills and upright drilling machines with V-belt drive

Convincing arguments: quality, efficiency and price
· Smooth running and powerful electrical motor
· Separate EMERGENCY-STOP push button
· 400 volt types with right-handed/left-handed rotation (except B 16H)
· Drilling depth stop
· Precisely machined drilling table with diagonally running T-slots
· 360 ° rotatable drilling table
· V-belt cover with safety switch
· V-belt tensioning device
· Long, ergonomic aluminium die-cast spindle sleeve lever made of one piece with Softgrip handles (OPTIdrill B 16H / B 24H)
· Spindle sleeve lever made of steel (OPTIdrill B 28H / B 34H )
· Solid, largely dimensioned base plate with slots, heavily ribbed at the rear side
· Base plate usable as a working surface for extra high workpieces due to the rotatable drilling table fromOPTIdrill B 28H on:
· Easy tool change due to integrated drill drift

Technical data and accessories







Αγορα Λεπτομερειες

OPTIdrill Β 28H


Robust bench drills and upright drilling machines with V-belt drive

Convincing arguments: quality, efficiency and price
· Smooth running and powerful electrical motor
· Separate EMERGENCY-STOP push button
· 400 volt types with right-handed/left-handed rotation (except B 16H)
· Drilling depth stop
· Precisely machined drilling table with diagonally running T-slots
· 360 ° rotatable drilling table
· V-belt cover with safety switch
· V-belt tensioning device
· Long, ergonomic aluminium die-cast spindle sleeve lever made of one piece with Softgrip handles (OPTIdrill B 16H / B 24H)
· Spindle sleeve lever made of steel (OPTIdrill B 28H / B 34H )
· Solid, largely dimensioned base plate with slots, heavily ribbed at the rear side
· Base plate usable as a working surface for extra high workpieces due to the rotatable drilling table fromOPTIdrill B 28H on:
· Easy tool change due to integrated drill drift

Technical data and accessories












Αγορα Λεπτομερειες

OPTIdrill Β 26Pro


Robust bench drills and upright drilling machines with V-belt drive

Convincing arguments: quality, efficiency and price
· Easy-to-operate safety switch according to IP 54 with undervoltage release and separate EMERGENCY-STOP push button
· 400 volt types with right-/left-handed rotation
· Drill depth stop
· Precisely machined drilling table with diagonally running T-slots
· Height adjustment of the drilling table via toothed rack
· The drilling table can be inclined by ± 45° and turned by 360°
· V-belt cover with safety switch
· Aluminium die-cast spindle sleeve lever made of one piece with

Softgrip handles
· Solid, largely dimensioned base plate with slots, heavily ribbed at the rear side (for OPTIdrill B 33Pro T-slots)
· Heavy type of the whole machine

Technical data and accessories








Αγορα Λεπτομερειες

EWM ALPHA Q 551


Technical Specifications
MIG / MAG WIG E-Hand
Setting range for welding current 5 A - 550 A
Duty at ambient temperature 40 °C 25 °C 40 °C 25 °C 40 °C 25 °C
60 % 550 A
80 % 520 A 520 A 520 A
100 % 420 A 450 A 420 A 450 A 420 A 450 A
Open-circuit voltage 93
Power frequency 50 Hz / 60 Hz
Mains fuse (slow) 3 x 32 A
Mains voltage (tolerances) 3 x 400 V (-25% - + 20%)
Max. Anschlussleistung 28.8 kVA 22.2 kVA 29.2 kVA
Rec. Generator power 39.4 kVA
cos phi 0.99
Efficiency 88 %
Drive rollers 4
Wire speed Drahtgeschwindigkeit m / min 0.5 m / min - 24 m / min
Drahtgeschwindigkeit ipm, 19.68 ipm - 944.88 ipm
Dimensions LxWxH in mm unit 1100 x 455 x 1000
Wire feed unit LxWxH in mm 660 x 280 x 380
Weight unit 138.5 kg
Weight wire feed 13 kg
Protection IP 23
Insulation class H
Cooling capacity 1500 W
Fuel capacity 12 l
Output 5 l / min
Max. Output pressure 3.5 bar
Standardize IEC 60974-1; -2; -10 / CE / S-mark / EMC Class A
Αγορα Λεπτομερειες

EWM WEGA 501 FDW


Technical Specifications
MIG / MAG
Setting range for welding current 50 A - 500 A
Duty at ambient temperature 40 °C 25 °C
60 % 500 A
70 % 500 A
100 % 400 A
Open-circuit voltage 50 V
Power frequency 50 Hz / 60 Hz
Mains fuse (slow) 3 x 32 A
Mains voltage (tolerances) 3 x 400 V (-15% - + 15%)
Max. Anschlussleistung 27.5 kVA
Rec. Generator power 32 kVA
cos phi 0.97
Dimensions LxWxH in mm unit 960 x 560 x 1010
Weight unit 200 kg
Switching stages 36 (12x3)
Protection IP 23
Insulation class H
Cooling capacity 1200 (1 l / min)
Fuel capacity 7 l
Output 5 l / min
Standardize IEC 60974-1; -5; -10 / CE / S-mark / EMC Class A
Αγορα Λεπτομερειες

EWM MIRA 251 FKG


Technical Specifications
MIG / MAG
Setting range for welding current 30 A - 250 A
Duty at ambient temperature 40 °C 25 °C
20 % 250 A
35 % 250 A
100 % 125 A 150 A
Open-circuit voltage 35 V
Power frequency 50 Hz / 60 Hz
Mains fuse (slow) 3 x 16 A
Mains voltage (tolerances) 3 x 400 V (-15% - + 15%)
Max. Anschlussleistung 9.6 kVA
Rec. Generator power 13 kVA
cos phi 0.97
Drive rollers 4
Wire speed 1.5 m / min - 20 m / min
Dimensions LxWxH in mm unit 880 x 385 x 610
Weight unit 60 kg
Switching stages 8
Protection IP 23
Insulation class H
Torch connection Euro central connection
Standardize IEC 60974-1; -5; -10 / CE / S-mark / EMC Class A
Αγορα Λεπτομερειες

EWM MICROPLASMA 20


Technical Specifications
Plasma
Setting range for welding current 0.1 A - 20 A
Secondary arc current 1 A - 10 A
Duty at ambient temperature 40 °C
100 % 20 A
Open-circuit voltage 95 V
Power frequency 50 Hz / 60 Hz
Mains fuse (slow) 1 x 16 A
Mains voltage (tolerances) 1 x 230 V (-40% - + 15%)
Max. Anschlussleistung 0.85 kVA
cos phi 0.99
Efficiency 86 %
Dimensions LxWxH in mm unit 520 x 550 x 480
Weight unit 50 kg
Protection IP 23
Insulation class H
Standardize IEC 60974-1; -3; -10 / CE / S-mark / EMC Class A

Αγορα Λεπτομερειες
